denso 10s20c AUTO ac Compressor for Honda Odyssey 6pk 2004-2006 38810PGM003 447170-6754 447220-3694 447220-3692 38810-PGM-003

Our factory can produce many kinds of auto Air Conditioner Compressors with good quality and one year quality warrantee.

DENSO 10S20C Honda Odyssey 6pk pulley ac compressor

Specification:

Model number: INTL-0221

Car name: Honda Odyssey

Type: 10S20C

Pulley: PV6

Volt: 12V

Clutch:120mm

Year:2004-2006

Special Notes:

OEM#

447170-6754

38810-PGM-003

4471706754

38810PGM003

Denso:

4472203694

4472203692

447220-3694

447220-3692

Details

2004-2006 Honda Odyssey compressor

10s20c Honda odyssey 2.4L compressor

Basic Requirements when servicing an A/C system:

1, The Accumulator or Filter Drier should always be replaced when the Air Conditioning System is opened. For warranty Purposes buyer must show evidence of receiver/drier replacement. In some vehicles the drier comes attached to the condenser so it must replaced as well

2. A/C system must be clean and free of debris and contaminants. In most cases components can be flushed; however in some instances it may be necessary to replace the condenser or other items.

3. Orifice tube must be replaced; expansion valve must be inspected and replaced if dirty or defective.

4. Correct amount and type of oil must be used. Please refer to the OE manufacturer for this information.

5. Prior to refrigerant charging, full vacuum must be done for a minimum of 45 minutes. In humid climates or during cooler days, this time should be increased to effectively remove air and boil off moisture.

6. The Orifice Tube, if equipped, should always be replaced and the Expansion Valve, if equipped, should at least be inspected for proper operation if not replaced
