auto air conditioning hose barb fitting hose connector aluminum crimp on fitting #10 90 degree male o-ring
- Price
- US $0.2-1
- Model
- INTL-HF2087
- MOQ
- 1 piece
Item specifics
- Material
- alumium
- Type
- Coupling
- Connection
- Male
- Head Code
- O-RING
- Item Type
- Air-conditioning Installation
- Quality
- high
- condition
- toally new
Review
Description
Item Type :Air-conditioning Installation
Material Type: aluminum
Car Make: universa
OE NO.: universal
warrant: 1 year
Size:#10 90 degree
model number:INTL-HF2087
Note: we can accord our customer dimension to manufacture
Jacket A | ||
Type | Rear Bore Diameter (MM) | Inner Bore Diameter(MM) |
A1:#6-5/16 | 8.2±0.3 | 15.2±0.4 |
A2:#8-13/32 | 11.4±0.4 | 18.4±0.4 |
A3:#10-1/2 | 13±0.4 | 21±0.5 |
A4:#12-5/8 | 15.2±0.4 | 23±0.5 |
Jacket B | ||
Type | Rear Bore Diameter (MM) | Inner Bore Diameter(MM) |
B1:#6-5/16 | 8.2±0.4 | 19±0.5 |
B2:#8-13/32 | 10.5±0.4 | 23±0.5 |
B3:#10-1/2A | 13±0.5 | 23±0.8 |
B4:#10-1/2B | 13±0.5 | 25.4±0.8 |
B5:#12-5/8 | 16.1±0.5 | 28.6±0.8 |
Note: we can accord our customer dimension to manufacture
