Portable refrigerant recovery machine,refrigerant recycle machine,refrigeration recover machine
- Price
- US $500-800
- Model
- INTL-RR004A
- MOQ
- 1 set
Item specifics
- Size
- 485mm(L) x230mm (W)x 365mm(H)(H)
- Type
- Other
- Motor
- 1/2HP
Review
Description
Portable Recovery Machine
1/2HP motor
1HP motor
Key Features:
1.Equipped with oil separator device;
2.1HP, oil-less compressor;
3.Heavy duty industrial grade condenser;
4.High pressure shut-off switch;
5.In-line Filter/Drier;
6.Optional 80% capacity shut-off kit.
Detailed Information:
Model | Refrigerants | Cat. III:R-12,R-134a,R-401C,R-406A,R-500 | |||
INTL-RR004 | Cat.IV:R-22,R-401A,R-401B,R-402B,R-407C,R-407D,R-408A,R-409A,R-411A,R-411B,R-412A,R-502,R-509 | ||||
Cat. V :R-402A,R-404A,R-407A,R-407B,R-410A ,R-507 | |||||
Power | 110-120V/50~60Hz;220-240V/50~60Hz | ||||
Motor | 1/2HP AC ;Capacitor start | ||||
Max.Current | 6A@50Hz 10A@60Hz | ||||
Compressor | Oil-less; air cooled; Two-piston | ||||
Refrigerant | Category III | Category IV | Category V | ||
Recovery | Vapor | 0.46kg/min | 0.50kg/min | 0.52kg/min | |
Rate | Liquid | 3.14kg/min | 3.62kg/min | 3.70kg/min | |
Push/Pull | 9.28kg/min | 11.04kg/min | 12.44kg/min | ||
High Pressure Shut-off | 38bar/550psi | ||||
Low Pressure Shut-off | Optional | ||||
80% OFP. Shut-off | Optional | ||||
Oil and Gas Separator |
| ||||
Operating Temp. | 0°C-40°C | ||||
Dimensions | 485mm(L) x230mm (W)x 365mm(H) | ||||
Net Weight | 17kg | ||||
Remarks Optional: | Oil and Gas separator; Dual Voltage 110/220V | ||||
