SANDEN 7H15 709 SD709 SD7H15 auto ac compressor Volvo
- Model
- INTL-C157
Item specifics
- Size
- PACKING : 25*22*19
- Type
- Compressor
- Car Make
- SANDEN 7H15 709 sd709 SD7H15 for Volvo
- OE NO.
- 6KS820803 20587125 85000458 8500458 4324 4134 4116
- QUALITY
- GRADE ONE
- pulley
- 8pk
- diameter
- 180mm
- volt.
- 24v
- HEAD PORT STYLE
- O-Ring
- NEW Original Sanden Compressor
- 4116 (1101060)
Review
Description
PRODUCT PROFILE
Specification:
Model number: INTL-C157
Car name for: Volvo trucks
Compressor Type: SD7H15 SD709
Clutch DIA: 180mm
Grooves: 8pk
Volt: 24V
OEM#
20587125
85000458
8500458
SANDEN:
4324
4134
4116
Details
COMPRESSOR for Volvo Trucks
INTL-C157 NEW Original Sanden Compressor 4116 (1101060)
COMPRESSOR FAMILY: SD7H15
STYLE: SPRHD
MOUNT TYPE: SD7 Direct Short
EAR ID: T92 B87
REFRIGERANT: R134A
DISPLACEMENT: 155.00
ROTATION DIRECTION: CW
OIL QTY (CC): 175
CYLINDER HEAD: WV
PORT ANGLE: H
PORT CLOCKING: Rear
HEAD PORT STYLE: O-Ring
ROTOR SIZE: 180
ROTOR GROOVE: PV8
GAUGE LINE
TO FIRST GROOVE: 31.58
GAUGE LINE
TO MIDDLE GROOVE: 44.09
GAUGE LINE
TO END GROOVE: 56.50
COIL VOLTAGE: 24
CONNECTOR: 1 Wire Bullet Volvo 1308436
SERVICE MANUAL: CLICK HERE
Cross References: 1101060, 54324, 300-5373, 4324, 20587125, 85000458, 20-04324, 4298, 4116U, 4116, 124783, PTAC54324, PTAC54298, 54298, 03-1202, 03-3550, 6KS820803 MACK, All w/8 gr 180 mm, Direct Mount, 1 wire 24V (4324), OEM# 6KS820803
Volvo/GM, All w/8 gr 180 mm, Direct Mount, 1 wire 24V (4324), OEM# 6KS820803
COMPRESSOR FAMILY: SD7H15
STYLE: SPRHD
MOUNT TYPE: SD7 Direct Short
EAR ID: T92 B87
REFRIGERANT: R134A
DISPLACEMENT: 155.00
ROTATION DIRECTION: CW
OIL QTY (CC): 175
CYLINDER HEAD: WV
PORT ANGLE: H
PORT CLOCKING: Rear
HEAD PORT STYLE: O-Ring
ROTOR SIZE: 180
ROTOR GROOVE: PV8
GAUGE LINE
TO FIRST GROOVE: 31.58
GAUGE LINE
TO MIDDLE GROOVE: 44.09
GAUGE LINE
TO END GROOVE: 56.50
COIL VOLTAGE: 24
CONNECTOR: 1 Wire Bullet Volvo 1308436
SERVICE MANUAL: CLICK HERE
Cross References: 1101060, 54324, 300-5373, 4324, 20587125, 85000458, 20-04324, 4298, 4116U, 4116, 124783, PTAC54324, PTAC54298, 54298, 03-1202, 03-3550, 6KS820803 MACK, All w/8 gr 180 mm, Direct Mount, 1 wire 24V (4324), OEM# 6KS820803
Volvo/GM, All w/8 gr 180 mm, Direct Mount, 1 wire 24V (4324), OEM# 6KS820803
