INTL MODEL:INTL-H001
GOODYEA Galaxy A10 8mm air conditioning hose 8MM
INNER DIAMETER:8.2MM±0.3
OUTER DIMETER:15.2MM±0.4
SPECIFICATION:
SINGLE Polyester spiral barrier hose
J51 AII Outside Diameters
Temperature Range -22°F to 257° F (-30°C / 125°C)
Compatible with
R-12 / R134a refrigerants
Mineral oil / PAG's
Meets J2064 "TYPE C Class II" Hose Performance
Low Volumetric Expansion
Dimensionally Stable
Flexible -- Easy to Route
GOOD YEA A10 HOSE SIZE SPECIFICATION:
A10 MODEL | INNER DIAMETER | OUTER DIAMETER |
A10A-8MM | 8.2±0.3 | 15.2±0.4 |
A10A-11.2 | 11.4±0.4 | 18.4±0.4 |
A10-13MM | 13±0.4 | 21±0.5 |
A10-15.2B | 15.2±0.4 | 23±0.5 |
NORMALLY WE ACCOR TO 20METER/ROLL TO SEND GOODS,OF COURSE ALSO CAN ACCOR TO CUSTOMER REQUIREMENTS TO CUT,IF YOU ORDER OTHER MODEL,BUT YOU CAN NOT FIND IN OUR WEBSITE, YOU CAN PLACE ORDER FIRST, THEN LEAVE MESSAGE TO US, AFTER WE GET YOUR MESSAGE,WE WILL ADJUST THE PRICE ACCOR TO YOUR MESSAGE WHAT YOU NEEDS,THEN YOU MAKE PAYMENT !
