Automotive Air Conditioning Refrigerant Leak Detector Heated Diode Sensor R CFCs HCFCs HFCs Freon Gas Leak Sniffer
Automotive Air Conditioning Refrigerant Leak Detector Heated Diode Sensor R CFCs HCFCs HFCs Freon Gas Leak Sniffer
Automotive Air Conditioning Refrigerant Leak Detector Heated Diode Sensor R CFCs HCFCs HFCs Freon Gas Leak Sniffer
Automotive Air Conditioning Refrigerant Leak Detector Heated Diode Sensor R CFCs HCFCs HFCs Freon Gas Leak Sniffer
Model
INTL-XG108

Item specifics

Size
Refrigerant Leak Detector
Type
tool
used
Universal
OE NO.
CFCs HCFCs HFCs Freon Gas Leak Sniffer

Review

Description


PRODUCT PROFILE

Model No.:  INTL-XG108

Refrigerant Leak Detector Heated Diode Sensor R CFCs HCFCs HFCs Freon Gas Leak Sniffer

Refrigerant Leak Detector offers the greatest sensitivity and fastest response of any portable refrigerant

detector available.This is achieved through the employment of a high sensitive heated diode sensor

combined with a sophisticated microprocessor-controlled circuit.



Sensor Principle Heating Semiconductor
Sensor life ≥500H
Refrigerant type CFCs HCFCs HFCS HFO
Warm-up time 60S
Maximum sensitivity 3g / yr
Display mode: LED screen
Battery type Li-240mA / h
Charging functionRechargeable
Probe length 36.5cm
Type of packagingBlow moulding box
Industry standard

EN14624

SAE-1627

SAE-2791



Features:
- Brand new appearance, unique shape; LED displays detailed information, such as battery, sensitivity, easy to operate;
- Imported sensor of heated diode nanotechnology and stabilivolt chip of high accuracy collect more than 5000 signals per seconds;
- Weighing recursive average filtering method; more accurate and stable;
- Wider detection range, besides common halogen refrigerants, new refri- gerants, such as R600A, R410A, etc. The accuracy can reach 3g/y;
- Sensitivity: 7 level adjustable(INTL-XG108);
- Battery display, low battery alarm function;
- Conform to CE standard and SAEJ1627 standard;
- Replaceable probe
- Rechargeable

Parameters:
Sensor: Heated Diode sensor
Minimum sensitivity: 3g/yr
Response time: <3s
Warm-up time: <60s
Operating temperature: 0℃~50℃;
Operating humidity: <80%RH (non-condensing)
The detector responds to all halogenated refrigerants (including Chlorine and Fluorine), which include but not limited to:
CFCs e.g. R12, R11, R500, R503 etc.
HCFCs e.g. R22, R123, R124, R502 etc.
HFCs e.g. R134a, R404a, R410a, R407C etc.
CH R600a

Package:
1x INTL-XG108
1x USB cable and Power Adapter
1x Manual
