FT 3006C A/C Refrigerant Hose Fitting Beadlock Crimp on Ferrule For Standard Barrier Hose #6 FR-1301
FT 3006C A/C Refrigerant Hose Fitting Beadlock Crimp on Ferrule For Standard Barrier Hose #6 FR-1301
FT 3006C A/C Refrigerant Hose Fitting Beadlock Crimp on Ferrule For Standard Barrier Hose #6 FR-1301
FT 3006C A/C Refrigerant Hose Fitting Beadlock Crimp on Ferrule For Standard Barrier Hose #6 FR-1301
FT 3006C A/C Refrigerant Hose Fitting Beadlock Crimp on Ferrule For Standard Barrier Hose #6 FR-1301
FT 3006C A/C Refrigerant Hose Fitting Beadlock Crimp on Ferrule For Standard Barrier Hose #6 FR-1301
Model
INTL-IJ8001

Item specifics

Material
aluminum
OE
429474 715008 715024

Review

Description

PRODUCT PROFILE








Product Description

INTL-IJ8001

Universal Air Conditioner FT 3006C A/C Refrigerant Hose Fitting Beadlock A/C Fittings, Crimp on Ferrule For Standard Barrier Hose #6

FR-1301

429474

715008

715024

16016

16816

1026826

3400

TEM200206

200206

TEM200216

3513006L

715024
Four Seasons: 16816
1026826
200206
TEM200206
3513006L
FT 3006

FITS FOR HOSE SIZE:#6

(HOSE I.D.:8MM O.D.:19MM)

SURFACE :STEEL

INTL NOOutside I.DInside I.D
INTL-IJ800119.5MM9.6MM
INTL-IJ800223MM12.3MM
INTL-IJ800324.3MM14.3MM
INTL-IJ800426MM14.3MM
INTL-IJ800529MM18MM
INTL-IJ800615.5MM9.6MM
INTL-IJ800718MM12.3MM
INTL-IJ800820MM15.6MM
INTL-IJ800924.3MM19.2MM



Related Hose Fitting



Female O-ring R-134a Beadlock Fitting (ALU. JOINT+ALU. JACKET)
Part NO.SpecificationPart NO.Specification
INTL-HF5201#6/StraightINTL-HF5207#10/Straight
INTL-HF5202#6/45°INTL-HF5208#10/45°
INTL-HF5203#6/90°INTL-HF5209#10/90°
INTL-HF5204#8/StraightINTL-HF5210#12/Straight
INTL-HF5205#8/45°INTL-HF5211#12/45°
INTL-HF5206#8/90°INTL-HF5212#12/90°
Related Ferrules
.jpg



Standard Jacket
Part NO.SpecificationB= Rear Bore Diameter (MM)A= Inner Bore Diameter(MM)C=length (MM)
INTL-AJ8101#6-5/168.2±0.419±0.535
INTL-AJ8102#8-13/3210.5±0.423±0.533
INTL-AJ8103#10-1/2A13±0.523±0.833
INTL-AJ8104#10-1/2B13±0.525.4±0.833
INTL-AJ8105#12-5/816.1±0.528.6±0.833



 Reduced Jacket
Part NO.SpecificationB= Rear Bore Diameter (MM)A= Inner Bore Diameter(MM)C=length (MM)
INTL-AJ8106A1:#6-5/168.2±0.315.2±0.435
INTL-AJ8107A2:#8-13/3211.4±0.418.4±0.433
INTL-AJ8108A3:#10-1/213±0.421±0.533
INTL-AJ8109A4:#12-5/815.2±0.423±0.533
Related Hose


Goodyear Standard Hose
Part NO.SpecificationI.D(MM)O.D(MM)
INTL-H008A20-5/168.2±0.419±0.5
INTL-H009A20-13/3210.5±0.423±0.5
INTL-H010A20-1/2B/C13±0.523±0.8
INTL-H010AA20-1/2A13±0.525.4±0.8
INTL-H011A20-5/816.1±0.525.4±0.8
